AMS 3196 Silicone Sponge Firm Density Closed Cell Silicone Sponge
What is AMS 3196 Closed Cell Silicone Sponge?
AMS 3196 silicone sponge is a firm density silicone type of closed cell silicone sponge rubber that meets the stringent requirements of the AMS 3196 specification. Ideal for sealing and gasket applications, this firm silicone sponge is designed to handle extreme conditions. It features a fabric finish on both sides, providing flexibility while withstanding harsh temperature environments. Additionally, it offers excellent compression set resistance, maintaining its resiliency even under extended compression.
Our Accreditations
Key Features
Excellent for Seals and Gaskets
Offers superior sealing performance for a wide range of applications.
High Compressibility
Ensures a snug fit and dependable functionality.
Low Compression Set
Retains its shape and sealing effectiveness over time.
UV/Ozone Resistant
Built to withstand environmental challenges, ensuring long-lasting durability.
Applications of AMS 3196 Closed Cell Silicone Rubber
AMS3196 closed cell silicone sponge is ideal for use in:
Seals and Gaskets: Provides reliable sealing solutions for aerospace, automotive, and industrial applications.
Thermal Insulation: Ideal for environments with extreme temperature variations.
Environmental Sealing: Protects against moisture, dust, and other contaminants.
Vibration Dampening: Used in applications requiring cushioning and vibration isolation.
Aerospace Components: Suitable for critical sealing in aircraft components.
- Automotive Parts: Ensures durability and performance in various automotive applications.
Industrial Equipment: Effective in sealing and insulating industrial machinery and equipment.
HVAC Systems: Used in heating, ventilation, and air conditioning systems for efficient thermal and acoustic insulation.
Material Availability
- Available in: Continuous rolls or cut sheets
- Thickness Available (in): 0.0625 to 0.500
- Typical Roll Lengths (ft): 25 to 100
- Typical Roll Widths (in): 36
- Surface Finishing: Fabric impression finish, both sides
- Cell Structure: Closed cell
Color: Red/orange, grey, black, white
Temperature Range
-103°F to +450°F (-75°C to 232°C)
Standards
- AMS3196
- FAR 25.853
Physical Properties
| Properties : | Standard : | |
| Compression Deflection (25%) | psi (kPa): 6-14 (41-96) | ASTM D1056 |
| Density < 0.25” Thick | pcf (kg/m³): 43 (690) max. | ASTM D1056 |
| Density ≥ 0.25” Thick | pcf (kg/m³): 34 (550) max. | ASTM D1056 |
| Compression Set (22h, 100°C) | %: 60 max. | ASTM D1056 |
| Tensile Strength | psi (kPa): 125 (862) | ASTM D412 |
More Information on AMS 3195
- Specification: AMS 3196 is a material specification for aviation applications created by the SAE International Group.
-
Forms Covered:
- Sheet
- Strip
- Extrusions
- Molded shapes
- Compliance: Our closed cell silicone sponge sheet meets the physical property requirements of the AMS3196 test standard.
-
Typical Applications:
- General applications requiring closed-cell, medium sponge rubber
- Flexible from -103°F to +401°F (-75°C to +205°C)
- Temperature Range: -103°F to +401°F (-75°C to +205°C)
- Flexibility: Maintains flexibility across the specified temperature range.
- Compression Set: May be high at the upper end of the temperature range.
- Usage: While typically used for general applications, its usage is not limited to these.
FAR 25.853
- Regulation: A section of the Federal Aviation Regulations (FARs)
- Focus: Addresses flammability requirements for materials used in the construction of commercial aircraft.
-
Requirements:
- Materials used inside the aircraft cabin must be flame-resistant.
- Includes items such as seat cushions, wall panels, and flooring.
- Fire Tests: Mandates materials must withstand specific fire tests.
-
Criteria and Methods:
- Specific criteria and test methods are outlined for assessing flammability.
- Ensures materials do not easily ignite and burn slowly, self-extinguishing if ignited.
-
Compliance Importanc:
- Critical for aircraft certification.
- Aims to enhance passenger safety by minimizing risks associated with in-flight fires.
Why choose Elastostar for your AMS 3196 Silicone Sponge Needs?
Choosing Elastostar ensures you receive top-quality AMS 3196 silicone sponge that meets stringent aerospace standards. Our firm density closed cell silicone sponge is known for its superior sealing and gasketing capabilities, making it ideal for a wide range of demanding applications including Aerospace.
We offer customizable solutions to meet your business needs. Our closed cell silicone is available in various forms, thicknesses, and colors to perfectly meet your specific needs. Furthermore, our dedicated customer service team is always ready to assist with any questions or special requirements, ensuring a seamless and satisfying purchasing experience.
